HUSQVARNA VIKING Large Metal Embroidery Hoop 240 x 150 mm | 920438096

HUSQVARNA VIKING Large Metal Embroidery Hoop 240 x 150 mm, #920438096. OEM Husqvarna Viking accessory supplied in branded packaging. The metal hoop uses removable magnets to hold fabric in place and lets you reposition the fabric between embroidery sections, which is especially useful for garments, quilts, seams, narrow areas and other projects that are difficult to hoop conventionally.

Embroidery area: 240 x 150 mm (approximately 9.5 x 6 in)
Part number: 920438096

Compatible HUSQVARNA VIKING models

Designer Brilliance 80; Designer Diamond; Designer Diamond Royale; Designer Diamond deLuxe; Designer Ruby; Designer Ruby Royale; Designer Ruby deLuxe; Designer Sapphire 85; Designer Epic; Designer Topaz 50.

Not compatible: Designer Topaz 20, Designer Topaz 25, Designer Topaz 30, Designer Topaz 40.

Instructions

1. Use this hoop only with a model in the compatible-model list. It does not fit Designer Topaz 20, 25, 30 or 40.
2. Choose stabilizer for the project: adhesive stabilizer for hard-to-hoop fabrics or finished garments, tear-away for standard embroidery, and water-soluble stabilizer for lace or free-standing work.
3. Position the fabric and stabilizer on the hoop. Space the magnets evenly to secure the layers, and keep excess garment fabric outside the embroidery area.
4. Between embroidery sections, lift off the magnets, reposition the fabric and secure it again before continuing.

Care: Lift magnets upward or roll them toward the hoop edge to remove them. Store them stacked away from the hoop when not in use; leaving them on the hoop can damage its flocked surface.

Bobbin changes: Raise the presser foot and carefully remove the hoop from the embroidery unit before changing the bobbin, then reattach it.

Official English PDF instructions for the Large Metal Hoop 240 x 150 mm (document 471018026A, © 2016).

1. Use this hoop only with a model in the compatible-model list. It does not fit Designer Topaz 20, 25, 30 or 40.

2. Choose stabilizer for the project: adhesive stabilizer for hard-to-hoop fabrics or finished garments, tear-away for standard embroidery, and water-soluble stabilizer for lace or free-standing work.

3. Position the fabric and stabilizer on the hoop. Space the magnets evenly to secure the layers, and keep excess garment fabric outside the embroidery area.

4. Between embroidery sections, lift off the magnets, reposition the fabric and secure it again before continuing.

Care: Lift magnets upward or roll them toward the hoop edge to remove them. Store them stacked away from the hoop when not in use; leaving them on the hoop can damage its flocked surface.

Bobbin changes: Raise the presser foot and carefully remove the hoop from the embroidery unit before changing the bobbin, then reattach it.
